AI 분석 플랫폼
정형 및 비정형 데이터를 수집하고, 분석 및 시각화를 통해 인사이트를 도출합니다.
다양한 산업 데이터에 최적화된 모델을 기반으로 의사결정 지원이 가능합니다.딥러닝 기반 솔루션
고도화된 딥러닝 기술을 통해 예측·분류·탐지 등의 자동화를 실현합니다.
복잡한 문제에 대한 대응력을 높이고, 상황에 맞는 유연한 처리 체계를 제공합니다.
| 항목 | 사양 |
|---|---|
| Frequency | L1, 1575.42 MHz |
| C/A Code | 1.023 MHz CHIP RATE |
| Acquisition Engine | 51 Channel |
| Tracking Engine | 14 Channel |
| Position | 2.5m CEP |
| Velocity | 0.1 m/s |
| Time pulse | 1PPS |
| Protocol | NMEA-0183 Version 3.01 |
| Hot Start | <1sec., Autonomous |
| Warm Start | <29sec., Autonomous |
| Cold start | <29sec., Autonomous |
| Tracking Sensitivity | -161dBm typical |
| Re-acquisition | -157dBm typical |
| Cold start | -148dBm typical |
| Altitude | 18,000m (Max) |
| Velocity | 515m/s (Max) |
| Acceleration | Less than 4G |
| Voltage | +5V ±0.3V |
| Supply current Tracking | 40mA 5V DC typical |
| Backup Battery Power | 3.0V / 10uA (include) |
| Elrctrical interface | Full dupiex serial communication |
| Baud Rate | 9,600bps, 8, 1, n |
| Navigation updata rate | 1Hz |
| Protocol Message | NMEA-0183 |
| Operation range | -30℃ ~ +85℃ |
| Storage range | -40℃ ~ +85℃ |
| Relative humidity | 5% ~ 80% |
| 항목 | 사양 | ||
|---|---|---|---|
| Processor | ARM Core | ||
| Memory | Extension : Nand Flash 64Mbyte | ||
| Internal : Flash 256Kbyte, Ram 48Kbyte | |||
| USB | Full speed (12Mbit/s) -Mass Stroage used (client) | ||
| Peripheral | UART | Output 2 channel | |
| (Rx, Tx, GND 3pin communication) | |||
| GPS Module | U-blox 7(GPS) / U-blox 8(GPS+GLONASS) : 65 channel | ||
| Frequency : L1 1574.42MHz | |||
| LTE Module | LIMEI : LML-M101 (LG U+) | ||
| I/O | 내부 Input 3 Button (버튼 입력) | ||
| 외부 Input 4 Port | |||
| Bluetooth | V2.1 + EDR (Opion) | ||
| LED | 6 LED (Status Display) | ||
| G sensor | Sensing extension shock | ||
| CAN | SN65HVD230 - 3.3V supply, 370uA | ||
| Power | Voltage | Input, DC 8V ~ 75V | |
| Ampare | Min : 200㎃ ~Max : 1.5A | ||
| Temperature | - 20℃ ~80℃ | ||
| Dimensions | 122(W) x 77(H) x 24(D) (mm) | ||
| 항목 | 사양 | ||
|---|---|---|---|
| Processor | ARM Core | ||
| Memory | Extension : Nand Flash 64Mbyte | ||
| Internal : Flash 256Kbyte, Ram 48Kbyte | |||
| USB | Full speed (12Mbit/s) - Mass Stroage used (client) | ||
| Peripheral | UART | Output 2 channel | |
| (Rx, Tx, GND 3pin communication) | |||
| GPS Module | U-blox 7(GPS) / U-blox 8(GPS+GLONASS) : 65 channel | ||
| Frequency : L1 1574.42MHz | |||
| LTE Module | Quectel : BG96 (SKT) | ||
| Teladin : TM700 (KT) | |||
| I/O | 내부 Input 3 Button (버튼 입력) | ||
| 외부 Input 4 Port | |||
| Bluetooth | V2.1 + EDR (Opion) | ||
| LED | 6 LED (Status Display) | ||
| G sensor | Sensing extension shock | ||
| CAN | SN65HVD230 - 3.3V supply, 370uA | ||
| Power | Voltage | Input, DC 8V ~ 75V | |
| Ampare | Min : 200㎃ ~Max : 1.5A | ||
| Temperature | - 20℃ ~80℃ | ||
| Dimensions | 122(W) x 77(H) x 24(D) (mm) | ||
| 항목 | 사양 | ||
|---|---|---|---|
| Processor | ARM926EJ-S-Embedded Linux | ||
| Memory | Nand Flash 125Mbyte | ||
| Ram 125Mbyte(DDR2) | |||
| USB | Full speed (12Mbit/s) - Mass Stroage used (client) | ||
| Peripheral | UART | Output 2 channel | |
| (Rx, Tx, GND 3pin communication) | |||
| GPS Module | U-blox 7(GPS) / U-blox 8(GPS+GLONASS) : 65 channel | ||
| GPS Frequency : L1 1574.42MHz | |||
| LTE Module | LIMEI : LML-M101 (LG U+) | ||
| I/O | 내부 Input 3 Button (버튼 입력) | ||
| 외부 Input 4 Port | |||
| Bluetooth | V2.1 + EDR (Opion) | ||
| LED | 6 LED (Status Display) | ||
| G sensor | Sensing extension shock | ||
| CAN | SN65HVD230 - 3.3V supply, 370uA | ||
| Ethernet | 10/100 BASE-T (1-포트) | ||
| Power | Voltage | Input, DC 8V ~ 75V | |
| Ampare | Min : 220㎃ ~Max : 1.5A | ||
| Temperature | - 20℃ ~80℃ | ||
| Dimensions | 122(W) x 77(H) x 24(D) (mm) | ||
| 항목 | 사양 | ||
|---|---|---|---|
| Processor | ARM Core | ||
| Memory | Extension : Nand Flash 64Mbyte | ||
| Internal : Flash 256Kbyte, Ram 48Kbyte | |||
| USB | Full speed (12Mbit/s) - Mass Stroage used (client) | ||
| Peripheral | UART | Output 1 channel | |
| (Rx, Tx, GND 3pin communication) | |||
| GPS Module | U-blox 7(GPS) / U-blox 8(GPS+GLONASS) : 65 channel | ||
| Frequency : L1 1574.42MHz | |||
| LTE Module | Quectel : BG96 (SKT / LG U+) | ||
| LED | 2 LED (Status Display) | ||
| G sensor | Sensing extension shock | ||
| Power | Voltage | Input, DC 8V ~ 75V | |
| Ampare | Min : 200㎃ ~Max : 1.5A | ||
| Temperature | - 20℃ ~80℃ | ||
| Dimensions | 83(W) x 62(H) x 17(D) (mm) | ||
